The attachment of ventilation ducts, ventilation pipes and other components such as silencers, cooling coils, etc. in different sizes and shapes can be found in residential, industrial and public buildings.
In the ventilation section, both horizontal and vertical laying is carried out and fastened accordingly.
The individual fastening of ventilation pipes is usually chosen because there are corresponding distances between the often visibly laid ventilation pipes. Fastening is then carried out directly to the substrate using dowels/anchors, threaded rods and ventilation pipe holders for horizontal installation.
In corridors, horizontal shafts and also vertical shafts, supply and exhaust air usually run in parallel at a close distance, so that joint fastening by means of mounting rails is recommended. These can be attached directly to the subfloor or by means of a frame construction to the ceiling, wall or floor, for both horizontal and vertical ventilation ducts or pipes. As an alternative to the mounting rails, jib brackets can also be used, which are preferably fastened to the wall in order to fasten one or more horizontal ventilation ducts or pipes. In general, fastening to steel structures can also be carried out using support brackets, etc. be carried out.
This gives us 55% time savings in our drilling operations
The concrete screw head fits geometrically perfectly into the FUS rail system
The girder clamp is the optimal fixing solution to steel structures without welding or drilling
The multi-hole design simplifies mounting with self-drilling screws or rivets and saves time.
