Art.-No. 513738

fischer Hammerfix N 5 x 50/25 F with flat head gvz

Top Features

Fast Hammerset installation saves time: ideal for series installation.
Simple and secure installation: Integrated hammer-in stop prevents premature anchor spreading.
Subsequent dismantling of the nail screw with a cross-slot recess is possible.
With flat head for metal constructions.

The ha mmer-in plug with flat head for simple, fast and economic installation.

Advantages

The rapid hammerset installation reduces the amount of time required and allows for an economic series installation.
The integrated hammer-in stop prevents the plug from expanding prematurely (jamming), thus enabling a problem-free installation.
Together with the cross-slot recess, the thread of the nail screw allows the screw to be removed, thus allowing for subsequent dismantling.
The wide range of diameters and usage lengths provides the correct plug for every fixing.

The fischer Hammerfix N-F with flat head consists of a high-quality nylon plug and a zinc-plated nail screw. These are pre-mounted for a fast installation process. The Hammerfix is inserted through the attachment part in a time-saving push-through installation. When the nail screw is hammered in, the plug sleeve expands and creates a secure anchoring in the building material. The fischer Hammerfix N-F with flat head is ideal for the fixing of metal constructions in all building materials.

Drill diameter ( d₀ )	5 mm
Effect. anchorage depth ( h_ef )	25 mm
Anchor length ( l )	50 mm
Min. drill hole depth for through fixings ( h₂ )	65 mm
Max. fixture thickness ( t _fix )	25 mm
Drive	PZ2
Packaging	Folding box
Amount	100 pcs.
GTIN (EAN-Code)	4048962128369
